Sonnet's Echo Express SEL - Thunderbolt 3 Edition enables you to connect a single low-profile PCIe card outside of the computer. Through its x8 PCIe 3.0 slot, this little Thunderbolt 3-to-PCIe card expansion chassis supports many Thunderbolt-compatible 16Gb and 8Gb Fibre Channel, 40Gb and 10 Gigabit Ethernet, video capture and processing, SAS and SATA host bus adapters, and RAID controller cards.
The Echo Express SEL - Thunderbolt 3 Edition features 40Gbps Thunderbolt 3, which offers double the speed and connectivity of Thunderbolt 2, and yields up to 2750 MB/s of PCIe bandwidth, enabling it to support 4K video capture and processing cards at high frame rates, and 16Gb FC cards and dual-port 10GbE cards at full performance. With the ability to handle the most demanding, highest performance PCIe cards, support for connecting two 4K displays @ 60Hz or one 5K display @ 60Hz, and support for a vast array of Thunderbolt and USB peripheral devices, Thunderbolt 3 is a leap forward in every way.
Features
- Connects a PCIe Expansion Card to Computers Without Slots - Use high-performance PCIe cards with any Mac or Windows PC with a Thunderbolt 3 port
- One PCIe 3.0 x8 Slot - Supports low-profile card
- 40Gbps Thunderbolt 3 Interface - Offers 2750 MB/s of PCIe bandwidth, doubling the performance of Thunderbolt 2
- Small Package, Full Performance - Smallest Thunderbolt 3-to-PCIe card expansion system available, supports the most popular low-profile, Thunderbolt-compatible PCIe cards at full performance
- Two Thunderbolt 3 (USB-C) Ports - One port reserved for connection to the computer; second port supports daisy-chaining of up to five additional Thunderbolt devices to your computer, attaching a single USB peripheral device, or connecting up to two 4K displays or one 5K display
- Remarkably Quiet - Temperature-controlled, variable-speed fan automatically and quietly cools the card
- Energy Saver Mode - Powers on/off automatically with the computer
- Rugged Aluminum Housing - Provides robust and secure protection
- Power for Peripherals - Provides up to 15W of power to connected peripheral or host
- Thunderbolt Cable & ThunderLok Included - Includes 0.5-meter Thunderbolt 3 (40Gbps) cable and ThunderLok 3 Thunderbolt connector retainer clip to secure cable from accidental disconnections
- Product Identifiers -
MPN: ECHO-EXP-SEL-T3UPC: 732311012044
- In The Box -
- Echo Express SEL - Thunderbolt 3 Edition Thunderbolt 3-to-PCIe Card Expansion System
- Power adapter
- Power cord
- 0.5-meter Thunderbolt 3 (40Gbps) cable
- Thunderbolt Connector Retainer Clip
- Documentation
- Note: PCIe card sold separately
- Product Specifications -
Compatibility
- Mac
- MacBook Pro (15-inch, Late 2016)
- MacBook Pro (13-inch, Late 2016, Four Thunderbolt 3 Ports)
- MacBook Pro (13-inch, Late 2016, Two Thunderbolt 3 Ports)
- Mac with Thunderbolt or Thunderbolt 2 ports and Apple Thunderbolt 3 (USB-C) to Thunderbolt 2 Adapter
- macOS™ 10.12.1+
- PC
- PC with a Thunderbolt 3
- Windows® 10, 8, 7
Important note: Your PC may require updates to insure that the Thunderbolt 3 ports function properly. - PCIe Card
For up-to-date PCIe card compatibility see Sonnet's PCIe Card Thunderbolt Compatibility Chart.
Technical Specifications
- Form Factor: Desktop Thunderbolt 3-to-PCIe card expansion system
- External Connectors: Two Thunderbolt 3 ports, power port
- Expansion Slot: One x8 PCIe 3.0 slot
- x8 Mechanical
- x4 Electrical (Thunderbolt 3 Spec)
- PCIe Cards Supported: One low-profile PCIe card
- Compatible PCIe Cards: Up-to-date PCIe cards listed on Sonnet's supporting PCIe Card Thunderbolt Compatibility Chart and as specified by card manufacturers
- Power Adapter: Universal 60W, 100-240V, 50-60 Hz
- Operating Temperature: 0°C to 35°C (32°F to 95°F)
- Dimensions (WxDxH): 4 x 8.25 x 2.8 in. (10.3 x 21 x 7.28 cm)
- Weight: 1.85 lbs (.84 kg)
- RoHS Compliant: Yes
- Warranty: 1-year
