The EIZO FlexScan S1934 is a 19-inch square-format monitor designed to meet the demands of professional environments such as offices and control rooms. With a native resolution of 1280 x 1024, this monitor offers a traditional 5:4 aspect ratio, providing ample vertical space for tasks like document editing, data analysis, and monitoring applications.
Equipped with an IPS (In-Plane Switching) panel, the FlexScan S1934 delivers consistent and accurate colors with wide 178° viewing angles, ensuring minimal color shift and contrast changes when viewed from different positions. This makes it ideal for collaborative work settings where multiple users may view the screen simultaneously.
To enhance user comfort during extended periods of use, the monitor features Auto EcoView, an ambient brightness sensor that automatically adjusts screen brightness in response to changes in the surrounding light. This function helps reduce eye fatigue by maintaining optimal screen brightness throughout the day. Additionally, the Paper mode preset reduces blue light emission by lowering the color temperature, further minimizing eye strain during prolonged reading or document editing sessions.
The FlexScan S1934 offers versatile connectivity options, including DisplayPort, DVI-D, and D-Sub mini 15-pin inputs, ensuring compatibility with both modern digital and legacy analog devices. This flexibility makes it suitable for various system configurations and future upgrades.
Designed with ergonomics in mind, the monitor comes with a stand that provides 100 mm height adjustment, 30° tilt, 70° swivel, and 90° rotation for portrait mode viewing. This adjustability allows users to position the screen at the most comfortable angle and height, reducing physical strain during long working hours.
In terms of energy efficiency, the FlexScan S1934 consumes just 9 watts during typical operation, representing a 25% reduction compared to its predecessor, the FlexScan S1933. This low power consumption contributes to a reduced environmental footprint and lower operating costs.
EIZO stands behind the quality and durability of the FlexScan S1934 with a five-year manufacturer's warranty, which is two years longer than the standard three-year warranty offered by most brands. This extended warranty underscores EIZO's commitment to providing reliable and long-lasting display solutions.
Features
- Display
- 19-inch square-format IPS panel with 1280 x 1024 native resolution
- 178° viewing angles for consistent image quality
- 250 cd/m² brightness and 1000:1 contrast ratio
- Connectivity
- DisplayPort, DVI-D 24-pin, and D-Sub mini 15-pin inputs
- HDCP support for secure content playback
- Ergonomics
- 100 mm height adjustment
- 30° tilt, 70° swivel, and 90° rotation for portrait mode
- Optional stand with 30° tilt only
- Eye Care Features
- Auto EcoView ambient brightness sensor
- Paper mode preset to reduce blue light emission
- Non-glare screen to minimize reflections
- Audio
- Dual 0.5-watt internal speakers
- Headphone jack for private listening
- Energy Efficiency
- Typical power consumption of 9 watts
- Compliance with international standards such as EPA Energy Star 7.0 and TCO Certified Displays 7
- Warranty
- Five-year manufacturer's warranty
- Product Identifiers -
MPN: S1934H-BKUPC: 690592042269
EAN: 4995047049234
- In The Box -
- Monitor
- AC power cord (2m)
- Signal cables (DVI-D (2m) , D-Sub mini 15 pin (1.8m))
- Audio cable (2.1)
- Setup guide
- Screw for VESA mount x4
- CD-ROM (PDF user's manual)
- Product Specifications -
- Model Variations: With Height Adjustable Stand, With Tilt Stand, Without Stand
- Cabinet Color: Black
- Panel
- Type: IPS
- Backlight: LED
- Size: 19" / 48 cm
- Native Resolution: 1280 x 1024 (5:4 aspect ratio)
- Viewable Image Size (H x V): 374.8 x 299.8 mm
- Pixel Pitch: 0.293 x 0.293 mm
- Display Colors: 16.77 million from a palette of 1.06 billion
- Viewing Angles (H / V, typical): 178°, 178°
- Brightness (typical): 250 cd/m2
- Contrast Ratio (typical): 1000:1
- Response Time (typical): 14 ms (Gray-to-Gray)
- Video Signals
- Input Terminals: D-Sub mini 15 pin x 1, DVI-D 24 pin x 1 (with HDCP), DisplayPort x 1 (with HDCP)
- Digital Scanning Frequency (H / V): 31 - 64 kHz, 59 - 61 Hz
- Analog Scanning Frequency (H / V): 31 - 64 kHz, 55 - 61 Hz
- Sync Formats: Separate
- Audio
- Speakers: 0.5 W + 0.5 W
- Input Terminals: 3.5 mm stereo jack
- Output Terminals: 3.5 mm headphone jack
- Sound Adjustment: Volume, Source (DisplayPort)
- Power
- Power Requirements: AC 100 - 240 V, 50 / 60 Hz
- Maximum Power Consumption: 21 W
- Typical Power Consumption: 9 W
- Power Save Mode: Less than 0.5 W
- Power Management: Power Save (VESA DPM and DVI DMPM)
- Features & Functions
- Preset Modes: Color mode (Paper, sRGB, User1, User2, DICOM)
- Auto EcoView: Yes
- OSD Languages: English, French, German, Italian, Japanese, Simplified and Traditional Chinese, Spanish, Swedish
- Physical Specifications
- Dimensions (Landscape, W x H x D)
- With Height Adjustable Stand: 405 x 406.5 - 506.5 x 205 mm
- With Tilt Stand: 405 x 414 x 205 mm
- Dimensions (Without Stand, W x H x D): 405 x 334 x 61.5 mm
- Net Weight
- With Height Adjustable Stand: 5.6 kg / 12.3 lbs
- With Tilt Stand: 4.6 kg / 10.1 lbs
- Net Weight (Without Stand): 3.8 kg / 8.3 lbs
- Height Adjustment Range
- With Height Adjustable Stand: 100 mm
- With Tilt Stand: -
- Tilt
- With Height Adjustable Stand: 30° Up, 0° Down
- With Tilt Stand: 30° Up, 5° Down
- Swivel
- With Height Adjustable Stand: 35° Right / 35° Left
- With Tilt Stand: -
- Pivot
- With Height Adjustable Stand: 90°
- With Tilt Stand: -
- Hole Spacing (VESA Standard): 100 x 100 mm
- Environmental Requirements
- Operating Temperature: 5 - 35 °C
- Operating Humidity (R.H., non condensing): 20 - 80 %
- Certifications & Standards (Please contact EIZO for the latest information.): TCO Certified Displays 7, EPEAT Gold (height adjustable stand version) / Silver (tilt stand version) (US), TUV/Ergonomics, TUV/GS, RCM, CE, CB, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, VCCI-B, EPA Energy Star, RoHS, WEEE, China RoHS, CCC, EAC
- Warranty: Five Years
